Setup Multi Region Openstack with Kolla Ansible

Setup Multi Region Openstack with Kolla Ansible

Introduction

This section (Research Purposes) describes how to perform a basic multiple region deployment with Kolla. A basic multiple region deployment consists of separate OpenStack installations in two or more regions (RegionOne, RegionTwo, …) with a shared Keystone.

Diagram

System Spesifications

Openstack Region bogor-1

Column 1 Column 2
Hostname op-bogor-aio
CPU 4 vCPU
RAM 12GB
DISK1 (system) 25GB
DISK2 (cinder) 100GB
Service Openstack Zed All in One
Internal FQDN op-bgr-rjhaikal.id

Openstack Region jakarta-1

Column 1 Column 2
Hostname op-jakarta-aio
CPU 4 vCPU
RAM 12GB
DISK1 (system) 25GB
DISK2 (cinder) 100GB
Service Openstack Zed All in One
Internal FQDN op-jkt-rjhaikal.id

Middleware Horizon

Column 1 Column 2
Hostname op-horizon
CPU 4 vCPU
RAM 4GB
DISK1 (system) 50GB
FQDN op-horizon-rjhaikal.id

IP Address

Node ens3 ens4 VIP
op-bogor-aio 192.168.1.50 none 192.168.1.100
op-jakarta-aio 172.16.1.50 none 172.16.1.100
op-horizon 10.20.10.200 - -

Deployment of the Bogor-1 Region

  1. Preparation
# Add Mapping Hosts
vim /etc/hosts
---
192.168.1.50 op-bogor-aio
172.16.1.50 op-jakarta-aio

192.168.1.100 op-bgr-rjhaikal.id
172.16.1.100 op-jkt-rjhaikal.id
---

# Install dependency
apt install python3-dev libffi-dev gcc libssl-dev ca-certificates -y
pip3 install docker

# Create Virtual Environment
mkdir openstack && cd openstack
python3 -m venv os-venv
source os-venv/bin/activate

2.   Install Ansible & Kolla-Ansible

# Install pip & ansible in virtual environment
pip install -U pip
pip install 'ansible>=4,<6'

# Install kolla-ansible
pip install git+https://opendev.org/openstack/kolla-ansible@stable/zed

# Install Ansible Galaxy dependencies (Zed release onwards):
kolla-ansible install-deps

3.   Configure Kolla-Ansible

# Create Kolla Folder
sudo mkdir -p /etc/kolla
sudo chown $USER:$USER /etc/kolla

# Copy inventory & yml file kolla
cp -r os-venv/share/kolla-ansible/etc_examples/kolla/* /etc/kolla
cp os-venv/share/kolla-ansible/ansible/inventory/* .

# Configure ansible
mkdir -p /etc/ansible
nano /etc/ansible/ansible.cfg
---
[defaults]
host_key_checking=False
pipelining=True
forks=100
---

# Generate kolla password
kolla-genpwd

# Configure globals.yml
nano /etc/kolla/globals.yml
globals.yaml
---
## BASE
kolla_base_distro: "ubuntu"
kolla_install_type: "source"
openstack_release: "zed"

## NETWORK
kolla_internal_vip_address: "192.168.1.100"
kolla_internal_fqdn: "op-bgr-rjhaikal.id"
network_interface: "ens3"
neutron_external_interface: "ens4"
neutron_plugin_agent: "ovn"
enable_neutron_provider_networks: "yes"

## SERVICE
nova_compute_virt_type: "qemu"
enable_haproxy: "yes"
enable_cinder: "yes"
enable_cinder_backup: "no"
enable_cinder_backend_lvm: "yes"
cinder_volume_group: "openstack_cinder"
keystone_token_provider: "fernet"
enable_keystone: "yes"
enable_horizon: "yes"
enable_openstack_core: "yes"
enable_mariadb_clustercheck: "yes"

## REGION
openstack_region_name: "bogor-1"
multiple_regions_names:
    - "{{ openstack_region_name }}"
    - "jakarta-1"

# Create Cinder Volume
pvcreate /dev/vdb
vgcreate openstack_cinder /dev/vdb

4.   Deployment

kolla-ansible -i ./all-in-one certificates (for generate self signed cert)
kolla-ansible -i ./all-in-one bootstrap-servers
kolla-ansible -i ./all-in-one prechecks
kolla-ansible -i ./all-in-one deploy
kolla-ansible -i ./all-in-one post-deploy

# Install Openstack Client
pip3 install openstackclient

# Verify Openstack Cluster
cp /etc/kolla/admin-openrc.sh ~/openstack
source ~/openstack/admin-openrc.sh
openstack endpoint list

Deployment of the Jakarta-1 Region

  1. Preparation
# Add Mapping Hosts
vim /etc/hosts
---
192.168.1.50 op-bogor-aio
172.16.1.50 op-jakarta-aio

192.168.1.100 op-bgr-rjhaikal.id
172.16.1.100 op-jkt-rjhaikal.id
---

# Install dependency
apt install python3-dev libffi-dev gcc libssl-dev ca-certificates -y
pip3 install docker

# Create Virtual Environment
mkdir openstack && cd openstack
python3 -m venv os-venv
source os-venv/bin/activate

2.   Install Ansible & Kolla-Ansible

# Install pip & ansible in virtual environment
pip install -U pip
pip install 'ansible>=4,<6'

# Install kolla-ansible
pip install git+https://opendev.org/openstack/kolla-ansible@stable/zed

# Install Ansible Galaxy dependencies (Zed release onwards):
kolla-ansible install-deps

3.   Configure Kolla-Ansible

# Create Kolla Folder
sudo mkdir -p /etc/kolla
sudo chown $USER:$USER /etc/kolla

# Copy inventory & yml file kolla
cp -r os-venv/share/kolla-ansible/etc_examples/kolla/* /etc/kolla
cp os-venv/share/kolla-ansible/ansible/inventory/* .

# Configure ansible
mkdir -p /etc/ansible
nano /etc/ansible/ansible.cfg
---
[defaults]
host_key_checking=False
pipelining=True
forks=100
---

# Copy passwords.yml Generated file from bogor-1
scp root@op-bogor-aio:/etc/kolla/passwords.yml /etc/kolla/passwords.yml

# Configure globals.yml
nano /etc/kolla/globals.yml
globals.yaml
---
## BASE
kolla_base_distro: "ubuntu"
kolla_install_type: "source"
openstack_release: "zed"

## NETWORK
kolla_internal_vip_address: "172.16.1.100"
kolla_internal_fqdn: "op-jkt-rjhaikal.id"
network_interface: "ens3"
neutron_external_interface: "ens4"
neutron_plugin_agent: "ovn"
enable_neutron_provider_networks: "yes"

## SERVICE
nova_compute_virt_type: "qemu"
enable_haproxy: "yes"
enable_cinder: "yes"
enable_cinder_backup: "no"
enable_cinder_backend_lvm: "yes"
cinder_volume_group: "openstack_cinder"
keystone_token_provider: "fernet"
enable_keystone: "no"
enable_horizon: "yes"

## REGION
openstack_region_name: "jakarta-1"
multiple_regions_names:
    - "{{ openstack_region_name }}"
    - "bogor-1"

kolla_internal_fqdn_r1: "op-bgr-rjhaikal.id"
keystone_admin_user: "admin"
keystone_admin_password: "P7NarU30uwjhxd30uxmyzx2EofCBokX4BbSpLH93"
default_user_domain_name: "Default"
keystone_internal_url: "http://op-bgr-rjhaikal.id:5000"
openstack_auth:
    auth_url: "{{ keystone_internal_url }}"
    username: "{{ keystone_admin_user }}"
    password: "{{ keystone_admin_password }}"
    user_domain_name: "{{ default_user_domain_name }}"
    system_scope: "all"

# Create Service Custom Config
mkdir -p /etc/kolla/config

cat<< EOF > /etc/kolla/config/global.conf
[keystone_authtoken]
www_authenticate_uri = http://op-bgr-rjhaikal.id:5000
auth_url = http://op-bgr-rjhaikal.id:5000
auth_type = password
EOF

cat<< EOF > /etc/kolla/config/nova.conf
[placement]
auth_url = http://op-bgr-rjhaikal.id:5000
auth_type = password
EOF

cat<< EOF > /etc/kolla/config/heat.conf
[trustee]
www_authenticate_uri = http://op-bgr-rjhaikal.id:5000
auth_url = http://op-bgr-rjhaikal.id:5000

[ec2authtoken]
www_authenticate_uri = http://op-bgr-rjhaikal.id:5000

[clients_keystone]
www_authenticate_uri = http://op-bgr-rjhaikal.id:5000
EOF

cat<< EOF > /etc/kolla/config/ceilometer.conf
[service_credentials]
auth_url = http://op-bgr-rjhaikal.id:5000
EOF
# Create Cinder Volume
pvcreate /dev/vdb
vgcreate openstack_cinder /dev/vdb

4.   Deployment

kolla-ansible -i ./all-in-one certificates
kolla-ansible -i ./all-in-one bootstrap-servers
kolla-ansible -i ./all-in-one prechecks
kolla-ansible -i ./all-in-one deploy
kolla-ansible -i ./all-in-one post-deploy

# Install Openstack Client
pip3 install openstackclient

# Verify Openstack Cluster
cp /etc/kolla/admin-openrc.sh ~/openstack
source ~/openstack/admin-openrc.sh
openstack endpoint list

+----------------------------------+-----------+--------------+----------------+---------+-----------+-------------------------------------------------+
| ID                               | Region    | Service Name | Service Type   | Enabled | Interface | URL                                             |
+----------------------------------+-----------+--------------+----------------+---------+-----------+-------------------------------------------------+
| 027b31457db541e39315555af7007149 | bogor-1   | glance       | image          | True    | internal  | http://op-bgr-rjhaikal.id:9292                  |
| 03e671ada70743c2ad0d9b3ef33991d8 | jakarta-1 | glance       | image          | True    | public    | http://op-jkt-rjhaikal.id:9292                  |
| 11e3f3f240884607966afa81a91cfb67 | bogor-1   | keystone     | identity       | True    | internal  | http://op-bgr-rjhaikal.id:5000                  |
| 219ba0ab7cb0429b9be7189983470b05 | bogor-1   | glance       | image          | True    | public    | http://op-bgr-rjhaikal.id:9292                  |
| 2805102ae5f1499ab04e04f7d748635c | bogor-1   | placement    | placement      | True    | internal  | http://op-bgr-rjhaikal.id:8780                  |
| 2be87e9e5dc04a4fa9317ab146c9f8f2 | jakarta-1 | heat-cfn     | cloudformation | True    | public    | http://op-jkt-rjhaikal.id:8000/v1               |
| 30e057451ecf450098aebe5ea3117006 | bogor-1   | placement    | placement      | True    | public    | http://op-bgr-rjhaikal.id:8780                  |
| 3154bab28b1b4967a19686515b6656a8 | bogor-1   | heat-cfn     | cloudformation | True    | internal  | http://op-bgr-rjhaikal.id:8000/v1               |
| 4e0dd0bf20644a66ae0b619b91fedc85 | jakarta-1 | heat         | orchestration  | True    | public    | http://op-jkt-rjhaikal.id:8004/v1/%(tenant_id)s |
| 55a8172691894f70951143be916ae8eb | bogor-1   | neutron      | network        | True    | public    | http://op-bgr-rjhaikal.id:9696                  |
| 57591f8103d9451b9ccec49fe2df2da3 | jakarta-1 | neutron      | network        | True    | public    | http://op-jkt-rjhaikal.id:9696                  |
| 5d0f71d971dd4579bd8f047fb85bfb84 | bogor-1   | heat         | orchestration  | True    | internal  | http://op-bgr-rjhaikal.id:8004/v1/%(tenant_id)s |
| 752f821360fa42d2a4105a8a22b947c1 | bogor-1   | nova         | compute        | True    | public    | http://op-bgr-rjhaikal.id:8774/v2.1             |
| 7a4452620dac4a3091373fbeb49f934b | jakarta-1 | cinderv3     | volumev3       | True    | internal  | http://op-jkt-rjhaikal.id:8776/v3/%(tenant_id)s |
| 7f5b182d90aa443a959ad8a4b1a11ac5 | bogor-1   | heat         | orchestration  | True    | public    | http://op-bgr-rjhaikal.id:8004/v1/%(tenant_id)s |
| 887e08610d3047af9a3a718196dddcb6 | jakarta-1 | placement    | placement      | True    | internal  | http://op-jkt-rjhaikal.id:8780                  |
| 9ecfe294dcec4010b015e31f5b71c1ef | jakarta-1 | cinderv3     | volumev3       | True    | public    | http://op-jkt-rjhaikal.id:8776/v3/%(tenant_id)s |
| a65d549a30da47ceb610211879519ace | bogor-1   | neutron      | network        | True    | internal  | http://op-bgr-rjhaikal.id:9696                  |
| b3841d8b89004999a9f5de3fa3855b75 | jakarta-1 | neutron      | network        | True    | internal  | http://op-jkt-rjhaikal.id:9696                  |
| be03f190466d407caf515bbf5193dc65 | jakarta-1 | keystone     | identity       | True    | internal  | http://op-bgr-rjhaikal.id:5000                  |
| bf271058f2204070b6c1986867986390 | bogor-1   | nova         | compute        | True    | internal  | http://op-bgr-rjhaikal.id:8774/v2.1             |
| d274c3960d894f5a8d6720c165c44bd6 | jakarta-1 | heat-cfn     | cloudformation | True    | internal  | http://op-jkt-rjhaikal.id:8000/v1               |
| d42c86fbbb0f47349496941adf05ed27 | bogor-1   | cinderv3     | volumev3       | True    | internal  | http://op-bgr-rjhaikal.id:8776/v3/%(tenant_id)s |
| d47f0499b5ce4ea59210ae2bb2bfb63e | jakarta-1 | heat         | orchestration  | True    | internal  | http://op-jkt-rjhaikal.id:8004/v1/%(tenant_id)s |
| da0c4828aeac4cb5b0abdb262cd6e347 | bogor-1   | heat-cfn     | cloudformation | True    | public    | http://op-bgr-rjhaikal.id:8000/v1               |
| e18e9112614d4aa4b71b87bb35ec1547 | jakarta-1 | placement    | placement      | True    | public    | http://op-jkt-rjhaikal.id:8780                  |
| e2727a1a1de24d4a96afec895ddc46c5 | bogor-1   | keystone     | identity       | True    | public    | http://op-bgr-rjhaikal.id:5000                  |
| e3fd5c6700f5410e95c96f4c1b7b154e | jakarta-1 | glance       | image          | True    | internal  | http://op-jkt-rjhaikal.id:9292                  |
| e593ff7fc1184a40987aad41faaedbd9 | jakarta-1 | keystone     | identity       | True    | public    | http://op-bgr-rjhaikal.id:5000                  |
| f6df440d2bb84bcd94fa978fbaea9573 | bogor-1   | cinderv3     | volumev3       | True    | public    | http://op-bgr-rjhaikal.id:8776/v3/%(tenant_id)s |
| fcb19de8ac29470c8387ec75ff629098 | jakarta-1 | nova         | compute        | True    | public    | http://op-jkt-rjhaikal.id:8774/v2.1             |
| fe86e77780b34ef0b0b6eeadbbfab3c7 | jakarta-1 | nova         | compute        | True    | internal  | http://op-jkt-rjhaikal.id:8774/v2.1             |
+----------------------------------+-----------+--------------+----------------+---------+-----------+-------------------------------------------------+

Login Test from Bogor-1 Horizon

Login Test from Jakarta-1 Horizon

Centralized Horizon Deployment

  1. Install Apache2 Web Server and Openstack Dashboard
vim /etc/hosts
---
10.20.10.200 op-horizon op-horizon-rjhaikal.id
192.168.1.50 op-bogor-aio
172.16.1.50 op-jakarta-aio

192.168.1.100 op-bgr-rjhaikal.id
172.16.1.100 op-jkt-rjhaikal.id
---

apt update
apt install apache2 libapache2-mod-wsgi-py3 openstack-dashboard

2.   Edit Openstack Dashboard Settings

vim /etc/openstack-dashboard/local_settings.py
---
DEBUG = False
ALLOWED_HOSTS = ['*']
AVAILABLE_REGIONS = [
    ('http://op-bgr-rjhaikal.id:5000', 'bogor-1'),
    ('http://op-bgr-rjhaikal.id:5000', 'jakarta-1'),
]

OPENSTACK_HOST = "op-horizon-rjhaikal.id"
OPENSTACK_KEYSTONE_URL = "http://op-bgr-rjhaikal.id:5000/v3"
OPENSTACK_KEYSTONE_DEFAULT_ROLE = "_member_"
TIME_ZONE = "Asia/Jakarta"
OPENSTACK_API_VERSIONS = {
    "identity": 3,
}
---

3.   Edit Openstack Dashboard Configuration for Apache

nano /etc/apache2/conf-enabled/openstack-dashboard.conf
---
WSGIScriptAlias /horizon /usr/share/openstack-dashboard/openstack_dashboard/wsgi.py process-group=horizon
WSGIScriptAlias / /usr/share/openstack-dashboard/openstack_dashboard/wsgi.py process-group=horizon
WSGIDaemonProcess horizon user=horizon group=horizon processes=3 threads=10 display-name=%{GROUP}
WSGIProcessGroup horizon
WSGIApplicationGroup %{GLOBAL}

Alias /static /var/lib/openstack-dashboard/static/
Alias /horizon/static /var/lib/openstack-dashboard/static/

<Directory /usr/share/openstack-dashboard/openstack_dashboard>
  Require all granted
</Directory>

<Directory /var/lib/openstack-dashboard/static>
  Require all granted
</Directory>
---

4.   Edit Horizon Virtual Host

nano /etc/apache2/sites-available/horizon.conf
---
<VirtualHost *:80>
        ServerName op-horizon-rjhaikal.id
        ServerAdmin webmaster@localhost

        DocumentRoot /usr/share/openstack-dashboard/openstack_dashboard/

        LogLevel warn
        ErrorLog ${APACHE_LOG_DIR}/error.log
        CustomLog ${APACHE_LOG_DIR}/access.log combined
</VirtualHost>
---

5.   Restart Apache2

a2dissite 000-default.conf
a2ensite horizon.conf
systemctl restart apache2

6.   Verify

Change Theme

Reference

Multiple Regions Deployment with Kolla — kolla-ansible 15.1.0.dev80 documentation
Install and configure for Ubuntu — horizon 23.1.0.dev66 documentation

Published by:

Raja Haikal

You might also like...

Feb
03

Set Up SSH to Use Two-Factor Authentication

Enhance the security of your SSH access by adding two-factor authentication (2FA) for an extra layer of protection on your
5 min read
Jan
26

Provision ArgoCD

Install Cert Manager We need certificates to be securely logon to the Argo CD UI. Certificate provisioning can be a
2 min read
Jan
20

Backup Restore Kubernetes with Velero & Swift

Hello World! Pada Artikel kali ini saya mau sharing ringan terkait riset yang sudah saya coba terkait Backup Restore Kubernetes
5 min read
Jan
15

Using RadosGW as a drop-in replacement for Swift

Hello Folks! Artikel ini lebih seperti catatan untuk diri sendiri, tetapi ini mungkin membantu jika anda mencari cara untuk mengintegrasikan
6 min read
Jan
10

Implement Oauth2 Proxy on Kubernetes

Sometimes, we may want to add authentication features to our service running on Kubernetes, but the application itself does not
5 min read

Member discussion
