How to Emulate SSD in KVM Virtual Machines

When working with KVM virtual machines to test setups like Ceph or OpenStack Clusters, it can be useful to have SSD storage available. Instead of using actual physical drives, you can emulate these storage types to achieve the same functionality for your testing purposes.

Emulate SSD Drives

SSD drives require a slightly different setup. To emulate an SSD, add a drive to your KVM guest as usual, specifying the desired bus (e.g., SCSI or SATA). Then, use the appropriate command to set the rotational speed to indicate it’s an SSD. Note that in QEMU, you set this value to 1, which translates to 0 in Linux (indicating a non-rotational drive).

To do this, you’ll need to know the exact device name, which depends on the number and type of drives you’ve added. Typically, the naming follows a pattern like scsi0-0-0-0 for the first SCSI drive on the first SCSI controller or sata0-0-0 for SATA drives. However, it’s always a good idea to verify the exact name.

Create Disk

qemu-img create -f qcow2 /var/disks3/vms/raja-lab-sda.qcow2 20G -o preallocation=full

Attach Disk with SCSI targetbus

virsh attach-disk raja-lab \
  --source /var/disks3/vms/raja-lab-sda.qcow2 \
  --target sda \
  --driver qemu \
  --subdriver qcow2 \
  --targetbus scsi \
  --persistent \
  --config \
  --live

You can confirm the device name by querying the guest using the virsh qemu-monitor-command tool, as shown below. Note the given id

virsh qemu-monitor-command raja-lab --hmp "info qtree" | grep scsi
---
      dev: virtio-scsi-pci, id "scsi0"
          dev: virtio-scsi-device, id ""
            bus: scsi0.0
              dev: scsi-hd, id "scsi0-0-0-0"
                device_id = "drive-scsi0-0-0-0"
                scsi_version = 5 (0x5)
                scsi-id = 0 (0x0)

Shutdown & Edit VM

virsh shutdown raja-lab
virsh edit raja-lab

<domain type="kvm" xmlns:qemu='http://libvirt.org/schemas/domain/qemu/1.0'>
...
  <qemu:override>
    <qemu:device alias='scsi0-0-0-0'>
      <qemu:frontend>
        <qemu:property name='rotation_rate' type='unsigned' value='1'/>
      </qemu:frontend>
    </qemu:device>
  </qemu:override>
</domain>

Start VM

virsh start raja-lab

Confirming drive is an SSD

You can confirm the rotational speed with lsblk, like so.

sudo lsblk -d -o name,rota

This will return either 0 (for rotational speed false, meaning SSD) or 1 (for rotating drives, meaning non-SSD). For example, here’s a bunch of drives on a KVM guest where you can see /dev/sda are SSD.

You can also check with smartctl, which will report the rotational rate as an SSD. Here’s an example on /dev/sda which is set to be an SSD in KVM guest.
